8.0 inch |
|
|
800(RGB)×1280 |
|
|
SPI (can be customized to MIPI, LVDS, eDP, etc.) |
|
|
107.64 × 172.22 mm |
|
|
114.70 × 184.25 × 6.00 mm |
|
|
1500 cd/m² |
|
|
85/85/85/85 (L/R/U/D) |
|
|
-30℃ ~ +80℃ (wide temp version) |
|
|
-40℃ ~ +85℃ |
|
|
50,000 hours |
|
|
0.7mm~3.0mm, AR/AG/AF coating optional |
- 1500cd/m² Ultra-High Brightness – Perfect for outdoor kiosks, vehicle displays, and sunlight-readable applications.
- Wide Operating Temperature Range (-30℃ to +80℃) – Ideal for industrial control panels, medical equipment, and outdoor vending machines.
- 50,000-hour LED Backlight Life – Extremely long lifespan, significantly reduces maintenance costs.
- – Interface, cover glass thickness, brightness, touch mode, mounting method, anti-glare/anti-fingerprint coating – everything can be tailored to your exact project requirements.
- – Consistent color and clarity from every direction, no color shift even at extreme angles.
- – 100% original raw materials, strict quality control, and 12-month warranty.
Our 8 inch LCD touch panel is widely used in:
We don't sell off-the-shelf products. We sell solutions. Tell us:
Our senior engineers will provide you with a free customized LCD solution within 48 hours, and you'll get the highest cost-performance product at the most reasonable price.
Q: Can I change the brightness to lower or higher than 1500cd/m²?
A: Yes. We can adjust from 500cd/m² up to 2500cd/m² according to your actual application.
A: Yes. We provide complete SDK, reference code, and technical support for Linux, Android, and Windows.
A: MOQ is 100pcs for custom projects. Samples are available at a reasonable price.
A: Standard products: 7-15 days. Customized products: 3-5 weeks (including tooling and testing).
